Hardinge Chucker Lathe HC with Threading HCT CF For Sale

Hardinge Chucker Lathe HC with Threading HCT CF For Sale
SPECIFICATIONS:



MAX FIXTURE DIAMETER …………….. 9″
MAX DISTANCE FROM FACE OF TURRET
    TO SPINDLE ………………….. 14″
SPINDLE CAPACITY
    WITH ROUND 5C COLLETS ………… 1-1/16″
    WITH 5C STEP CHUCKS ………….. 1-1/16″ TO 6″
    WITH JAW CHUCKS ……………… 6″
SPINDLE TAPER …………………… HARDINGE THREADED NOSE
TRAVEL OF CROSS SLIDE ……………. 4-1/2″
CROSS SLIDE POWER FEED RANGE ……… 11/32 TO 6-1/4 IPM
CARRIAGE POWER FEED RANGE ………… 1/4 TO 10 IPM
VARIABLE SPINDLE SPEEDS, (3 SELECTOR)
    LOW SPEEDS ………………….. 125 – 1,100 RPM
    HIGH SPEEDS …………………. 1100 – 3,000 RPM
MAX DIAMETER FOR THREADING ……….. 6″EXTERNAL, 5″INTERNAL
APPROXIMATE WEIGHT ………………. 1,750 LBS.

EQUIPPED WITH:
  • HARDENED AND GROUND DOVETAIL BED
  • LEVER-TYPE COLLET CLOSER FOR TYPE 5C COLLETS
  • INDEPENDENT ELECTRICAL VARIABLE POWER FEED TO CARRIAGE
  • EIGHT STATION CROSS FEEDING TURRET
  • EIGHT POSITION TURRET-TYPE CARRIAGE STOP
  • HARDINGE THREADING ATTACHMENT



MACHINE WIRED FOR THREE PHASE 60 CYCLE 230 VOLT OPERATION
Hardinge Chucker Lathe 1 Hardinge Chucker Lathe 2 Hardinge Chucker Lathe 3 Hardinge Chucker Lathe 4 Hardinge Chucker Lathe 5 Hardinge Chucker Lathe 6 Hardinge Chucker Lathe 7 Hardinge Chucker Lathe 8 Hardinge Chucker Lathe 9

Monarch Metal Lathe Model No. 61 13×30

Monarch Metal Lathe No. 61


Tag reads:

Lathe: 13×30
Type: Tool Makers
Serial: 43667
Date of Mfg: 2-59
Model No. 61
Weight: 5145
6 Jaw Chuck
Please note the digital read out display is missing
Monarch (1) Monarch (2) Monarch (3) Monarch (4) Monarch (5) Monarch (6) Monarch (7) Monarch (8)



Monarch Metal Lathe – 72″ Between Centers

Monarch Metal Lathe – 72″ Between Centers

  • Tag reads:
  • Catalog size: 20″
  • Serial: 41551
  • Actual swing: 22.5″
  • Distance between centers: 72″
  • Year: 1956
We did a little looking and have found these specs from other sources for the Monarch lathe.  These specs are to the best of our knowledge……that being said, you will want to double check the info using the serial number or physical inspection.

Machine Details:

  • MODEL ………………………… 20CM
  • SWING OVER WAYS ……………….. 22-1/2″
  • DISTANCE BETWEEN CENTER ………… 72″
  • SWING OVER CROSS SLIDE …………. 13″
  • SPINDLE SPEEDS ………………… (12) 9 TO 400 RPM
  • FEEDS ………………………… (48) .005 TO .240 IPR
  • THREADS ………………………. (48) 3/4 TO 46 TPI
  • DIAMETER OF SPINDLE HOLE ……….. 2-1/4″”
  • TAPER ATTACHMENT ………………. YES
  • SWIVEL COMPOUND ……………….. YES
  • THREAD DIAL …………………… YES
  • HARDEN WAYS …………………… YES
  • SPINDLE FORWARD & REVERSE ………. YES
  • COOLANT WITH CHIP PANS …………. YES
  • MOTOR ………………………… 10 HORSEPOWER

Monarch Metal Lathe 1 20140626_152932 20140626_152911 20140626_152853 20140626_152842Monarch Metal Lathe 2 Monarch Metal Lathe 3 Monarch Metal Lathe 4
