800 Ton Dieffienbacher Hydraulic Press For Sale

800 Ton Dieffienbacher Hydraulic Press For Sale

  • Year: 2003
  • Capacity: 800 Metric Tons (880 US Tons)
  • Total weight of the press 43,000kg (95,000lbs)
  • L-R 1400mm (55.18″)
  • F-B 1440mm (56.69″)
  • Daylight 1400mm (55.18″)
  • Stroke: 1000mm (39.37″)
  • Bolster Size 1070mm (42.13″) Depth x 1970mm (77.56″) L-R x 1640mm (64.57″) F-B
  • Pressure Speed 10-40mm/sec (0.39″ to 1.57″) Closing Speed
  • Max Pressure 320 Bar

800 Ton Dieffienbacher Press For Sale Hydraulic800 Ton Dieffienbacher Press For Sale Hydraulic800 Ton Dieffienbacher Press For Sale Hydraulic800 Ton Dieffienbacher Press For Sale Hydraulic800 Ton Dieffienbacher Press For Sale Hydraulic

2000 Ton Macrodyne Hydraulic Press For Sale Used

2000 Ton Macrodyne Hydraulic Press For Sale Used

  • Model: MPH2000
  • Year: 2002
  • Capacity: 2,000 Tons
  • Bed: 118″ x 70″
  • Daylight: 98″
  • Stroke: 26″
  • Includes: (3) Motorman UP165-100 Robots w/Controller, (2) Motoman UP50 w/controller, (3) Skids of metal grating, drip trays and metal stands, Complete with accessories

150 Ton Capacity Pacific Hydraulic Press For Sale

150 Ton Capacity Pacific Hydraulic Press

  • Capacity: 150 Ton
  • Model: 150-FC OBS/PF
  • Serial: A1256
  • Stroke: 12″
  • Year: 1996
  • Open Daylight: 26″
  • Closed Daylight: 14″
  • Weight: 37,000lbs.
  • Bed Area: 50″ LR x 30″ FB (T-Slotted)
  • Ram Area: 34″ LR x 24″ FB (T-Slotted)
  • Bolster: 50″ x 30″ x 4 1/2″ w/o Vibro Pads
  • Ram Speeds:
    • 900 IPM Fast Advance
    • 15-160 IPM Pressing Speed
    • 800 IPM Fast Return
  • Motor: 60hp
  • Floor to Bed: 36″
  • Dimensions: 60″ x 88″ x 126″ High
  • Weight: 36,000lbs.
  • Equipped With:
    • Wintriss SmartPac 2 Hydraulic Press Control
    • Scale Feedback for Ram Positioning
    • Inch/Single/Continuous Operation
    • Trabon Lube System
    • 8-Point Gib Guided Ram
    • Cushion
    • Allen Bradley PLC
    • Vibro Dynamics Isolation Pads
    • Separate Control Console
    • Adjustable Pressing Speeds
    • Floor Standing Design
  • *Preliminary Specs: Subject to Verification

150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale 150 Ton Capacity Pacific Hydraulic Press For Sale

400 Ton Capacity Macrodyne Press For Sale

400 Ton Capacity Macrodyne Press For Sale – SOLD Call for updated inventory

  • Capacity: 400 Tons
  • Bed Size: 100″ x 96″
  • Stroke: 16″
  • Shut Height: 32″
  • Year: 2006
  • Overall Height: 23′
  • Fast Approach Speed: 510″/min.
  • Pressing Speed: 35″/min.
  • Max Return Speed: 500″/min.
  • Press Cycle Time @ 16″: 5.6 sec.



25 Ton Used Dake C Frame Hydraulic Press For Sale

Dake C Frame Hydraulic Press For Sale – Used

2 Post Guided Platen Design
Year 1994
Capacity: Pressing 25 Tons
               Return 10 Tons
Speed: Rapid Advanced 394 IPM
           Pressing 53 IPM
           Return 411 IPM
Stroke: 21″
Daylight 40″
Bed Area 48″ x 22″
Slide Area 34″ x 15 3/4″
Overall Dimension — Height 121″ x 54″ Wide x 62″ Front to Back
Motor 10 HP – 1200 RPM – 460 Volt – 3 Phase – 60 Cycle
Equipped with: Allen Bradley Control, STI light curtains
Note: Press has been sitting in storage for some time and needs to be cleaned up



25 Ton Used Dake C Frame Hydraulic Press For Sale 25 Ton Used Dake C Frame Hydraulic Press For Sale

150 Ton Federal Hydraulic Spotting Press For Sale

150 Ton Federal Hydraulic Spotting Press For Sale

www.Affordable-Machinery.com or Call 616-200-4308

  • Capacity: 150 Tons
  • Bolster Plate: 144″ x 100″
  • Stroke: 60″
  • Daylight: 96″
  • Between Uprights: 156″
  • Height Above Floor: 189″
  • Weight: 199,420lbs. (Approx.)
  • Equipped With: Hydraulic Moving Bolster

150 Ton Federal Hydraulic Spotting Press For Sale (Small Bolster) 1 150 Ton Federal Hydraulic Spotting Press For Sale (Small Bolster) 2

150 Ton Federal Hydraulic Spotting Press For Sale

150 Ton Federal Hydraulic Spotting Press For Sale

  • Capacity: 150 Tons
  • Bolster Plate: 200″ x 100″
  • Stroke: 60″
  • Daylight: 96″
  • Between Uprights: 212″
  • Height Above Floor: 189″
  • Weight: 228,750lbs. (Approx.)
  • Equipped With: Hydraulic Moving Bolster



150 Ton Federal Hydraulic Spotting Press For Sale (Big Bolster) 1150 Ton Federal Hydraulic Spotting Press For Sale (Big Bolster) 2
