2″ Ajax Upsetter For Sale

2″ Ajax Upsetter

  • Header Slide Load Rating: 400 Tons
  • Die Grip Rating: 248 Tons
  • Approx. Total Weight: 39,000 lbs
  • Floor Space (L-R x F-B): 7′ 0″ x 10′ 8″
  • Height Above Floor: 6′ 8″
  • Distance Below Floor: 0′ 6″
  • Operating Air Pressure: 75 PSI
  • Main Motor: 5 HP/900 RPM
  • Gear Ratio: 18/77
  • Strokes Per Minute: 55 SPM
  • Header Slide Stroke: 9″
  • Die Opening: 3 1/2″
  • Stock Gather: 6″
  • Hold-On: 2 1/2″
  • Die Height: 14″
  • Die Thickness: 6″
  • Die Seat Length: 13″
  • Tool and Die Space (max.): 28 1/2″
  • Flywheel Diameter: 41″
  • Clutch: 21″ – 4 Plate
  • Journal Clearances: .008 – .010″
  • Header Slide Clearances:
    • Body: .011 – ,013″
    • Tail: .007 – .009″
  • Die Slide Clearances:
    • Body: .016 – .018″
    • Tail: .011 – .013″
  • Cam Slide Clearances:
    • Body: .008 – .010″

220 Ton Capacity Aida Single-Point Gap Press For Sale

220 Ton Capacity Aida Single-Point Gap Press

  • Model: NC1-200(2)
  • Year: New in 1990
  • Capacity: 220 Ton
  • Bed Area: 55″ x 33″
  • Stroke: 9.5″
  • Shut Height: 26.5″ to Bed
  • Slide Adj.: 4″
  • Slide Surface Area: 35″ x 27″
  • Speed: 38 SPM
