Category Archives: Used Metal Stamping Presses For Sale

Used Metal Stamping Presses For Sale – we buy and sell such brands as Minster, Verson, Clearing, Bliss, Danly, Komatsu, Aida, Stamtec and more. If you are in the market for a used press or other used machines, let us know. Dealing in High Speed Presses, Straight Side Presses, Hydraulic Presses, Molding Presses, OBI Presses, Gap Presses, used Feed Lines, Coil Reels, Coil Cradles and Used Punch presses.

330 Ton Capacity Niagara Straight Side Press For Sale

Posted on by

330 Ton Capacity Niagara Straight Side Press

  • Model: SC2-300-120-60
  • Capacity: 330 Tons
  • Bed Area: 120″ LR x 60″ FB
  • Slide Area: 120″ LR x 60″ FB
  • Stroke: 12″
  • Adjustment: 12″
  • Shut Height: 30″ (over bed)
  • Speed: 30-60 SPM
  • Note:
    • Window Opening: 32″ W x 20″ H
    • Total Weight: 117,500 lbs (approx.)
    • Overall Height: 207″ (above floor)
    • Bolster Thickness: 7.5″

440 Ton Capacity Aida Straight Side Link Motion Press For Sale

Posted on by

440 Ton Aida Straight Side Link Motion Metal Stamping Press

  • Capacity: 440 US Tons (400 KN) at 0.25″
  • Model: PMX-L2-4000(1)-225-160
  • Year: 2002
  • Stroke: 12″
  • Slide Adjustment: 6″
  • Speed: 25 to 60 SPM
  • Micro Inching: 10 SPM
  • Shut Height: 43″
  • Bed Area: 108.26″ x 55″
  • Slide Area: 108.26″ x 55″
  • Bolster Thickness: 10.62″
  • Overall Height: 257.87″
  • Window Size: 53.53″ Wide
  • Total Weight: 97 Tons



400 Ton Capacity Heim Straight Side Press For Sale

Posted on by

400 Ton Capacity Heim Straight Side Press

  • Model: S2-400-100-48
  • Stroke: 12″
  • Shut Height: 12″
  • Slide Adjustment: 12″
  • Speed: 20 – 40 SPM (Variable)
  • Bed Area: 100″ x 48″
  • Ram Area: 100″ x 48″
  • Includes:
    • T-Slotted Bolster (Approx. 6″ Thick)
    • Windows in Uprights
    • Tie Rod Construction
    • Fabricated Steel Frame
    • Air Clutch & Brake
    • Air Counter Balances
    • Hydraulic Overload Protection
    • Light Curtains
    • Imco Tonnage Motor
    • Motor & Controls

1,000 Ton Capacity Komatsu Straight Side Press For Sale

Posted on by

1,000 Ton Capacity Komatsu Straight Side Press

  • Model: E5T1000-MF-C
  • Year: 1997
  • Capacity: 1,000 Tons
  • Bed & Slide Area: 4000mm x 1920mm (157.48″ x 76″)
  • Bolster: 4000mm x 2000mm x 270mm (157.48″ x 79″ x 11″)
  • Stroke: 450mm (18″)
  • Die Height: 1150mm (45″)
  • Adjustment: 200mm (8″)
  • Speed: 10-25 SPM
  • Includes:
    • Coil Feed Line

2,000 Ton Capacity Danly Straight Side Press

Posted on by

2,000 Ton Capacity Danly Straight Side Press

  • Model: SE-2000-180-84TF
  • Year: 1983
  • Total Capacity: 2000 Tons
  • Bed Area: 180″ x 84″
  • Slide Area: 180″ x 84″
  • Stroke: 28″
  • Slide Adjustment: 8″
  • Shut Height: 64″
  • Speed: 10 to 20 SPM
  • Windows: 136″ Wide
  • Completely Rebuilt in 2010
  • Equipped With:
    • Moving Bolsters

800 Ton Dieffienbacher Hydraulic Press For Sale

Posted on by

800 Ton Dieffienbacher Hydraulic Press For Sale

  • Year: 2003
  • Capacity: 800 Metric Tons (880 US Tons)
  • Total weight of the press 43,000kg (95,000lbs)
  • L-R 1400mm (55.18″)
  • F-B 1440mm (56.69″)
  • Daylight 1400mm (55.18″)
  • Stroke: 1000mm (39.37″)
  • Bolster Size 1070mm (42.13″) Depth x 1970mm (77.56″) L-R x 1640mm (64.57″) F-B
  • Pressure Speed 10-40mm/sec (0.39″ to 1.57″) Closing Speed
  • Max Pressure 320 Bar
