C&B Machinery Disc Grinder Wheel Change Assist For Sale -Gardner, Besly, Mattison, Giustina

Posted on by

C&B Machinery Double Disc Grinder Wheel Change Assist For Sale -Gardner or Besly, Mattison, Giustina – Used

“The M30/36HDDW unit shown here can hold four wheels and backing plates for the common disc grinders such as C&B, Giustina, Besly, Gardner and Mattison, Koyo and more.

  • All the models will accommodate up to 36-inch diameter disc grinding wheels.

  • All models can be towed behind in-plant vehicles.

  • Also, each model can be towed behind each other.

  • Two wheels are swivel and come with roller locks.”

Stock Photo

stock photo

Davis No. 4 Mechanical Vertical Keyseater Keyway Broach Cutter For Sale

Posted on by

Davis No. 4 Mechanical Vertical Keyseater Keyway Broach Cutter For Sale

(we did some research on the specifications and this is what we came up with, you may want to double check it yourself before purchasing)

Brand: Davis

Model: No. 4

Approx. Shipping Weight: 1,500 Lbs.

Approx. Shipping Dimensions: 48″ L x 40″ W x 60″ H

Specifications:

Size: 3/4″ Max

Stroke: 4-1/2″

Table Size: 24-1/2″ x 26-1/2″ w/ (1) T-Slot

Table Movement: 1-1/8″

Strokes Per Minute: 48

Maximum Height of Work: 8″

Keyway Cutting: 1/16″ to 3/4″

Motor HP: 1.5

Electrical: 230V/440V 3PH

200 Ton Capacity Riggers Manufacturing Gantry For Sale

Posted on by

200 Ton Capacity Riggers Manufacturing Gantry For Sale – Used

(UPDATE – One 200 Ton Set Left – EZ200)

  • Capacity: 200 Tons
  • Model EZ200
  • Retracted Height: 8′ 6 1/2″
  • Extended Height: 20′
  • Unit is Self-Propelled
  • Weight of Each Leg: 11,000 lbs
  • Reservoir Capacity: 170 gallons
  • Operating Voltage: 440 Volts 3-Phase 30 AMPS
  • Cylinders: 2 Stage Telescopic
  • No Beams
  • No Runway

200 Ton EZ200 Riggers Gantry For Sale

250 Ton Verson Gap Frame Single-Point Press For Sale

Posted on by

250 Ton Verson Gap Frame Single-Point Press For Sale – Used

  • Model: 12F O.B.G.
  • Total Capacity: 250 Tons
  • Bolster Area: 62″ x 36″
  • Slide Area: 52″ x 34″
  • Stroke: 10″
  • Slide Adjustment: 5″
  • Shut Height: 32″ SDAU
  • Speed: 40 SPM

250 Ton Capacity Verson Single-Point Gap-Frame Press For Sale250 Ton Capacity Verson Single-Point Gap-Frame Press For Sale250 Ton Capacity Verson Single-Point Gap-Frame Press For Sale250 Ton Capacity Verson Single-Point Gap-Frame Press For Sale

600 Ton Rigger Mfg EZ604 Hydraulic Gantry Crane System For Sale

Posted on by

600 Ton Rigger Mft EZ604 Hydraulic Gantry Crane System For Sale – Used

  • Model: EZ604
  • Make: E-Z Lifter
  • Control System: CARL
  • Year: 2002
  • Capacity 600 Tons @15′ 1.5″ — 225 Tons @ 33′ 0.05″
  • Legs: 4 Self-Propelled Continuous Travel
  • Reservoir Capacity: 330 gallons
  • Operating Voltage: 440v 60Hz or 380v 50Hz
  • Current Draw: One Leg 21 amps – Two Legs 42 amps
  • Cylinders: 4 Stage
  • Horsepower: 20hp
  • Weight Each: 26,500lbs

600 Ton EZ604 Riggers Hydraulic Gantry For Sale600 Ton EZ604 Riggers Hydraulic Gantry For Sale600 Ton EZ604 Riggers Hydraulic Gantry For Sale600 Ton EZ604 Riggers Hydraulic Gantry For Sale600 Ton EZ604 Riggers Hydraulic Gantry For Sale600 Ton EZ604 Riggers Hydraulic Gantry For Sale

From Riggers Mfg Brochure, actual item show in different image.

600 Ton EZ604 Riggers Hydraulic Gantry For Sale
