Category Archives: by Manufacture

440 Ton Capacity Aida Straight Side Link Motion Press For Sale

Posted on by

440 Ton Aida Straight Side Link Motion Metal Stamping Press

  • Capacity: 440 US Tons (400 KN) at 0.25″
  • Model: PMX-L2-4000(1)-225-160
  • Year: 2002
  • Stroke: 12″
  • Slide Adjustment: 6″
  • Speed: 25 to 60 SPM
  • Micro Inching: 10 SPM
  • Shut Height: 43″
  • Bed Area: 108.26″ x 55″
  • Slide Area: 108.26″ x 55″
  • Bolster Thickness: 10.62″
  • Overall Height: 257.87″
  • Window Size: 53.53″ Wide
  • Total Weight: 97 Tons



400 Ton Capacity Heim Straight Side Press For Sale

Posted on by

400 Ton Capacity Heim Straight Side Press

  • Model: S2-400-100-48
  • Stroke: 12″
  • Shut Height: 12″
  • Slide Adjustment: 12″
  • Speed: 20 – 40 SPM (Variable)
  • Bed Area: 100″ x 48″
  • Ram Area: 100″ x 48″
  • Includes:
    • T-Slotted Bolster (Approx. 6″ Thick)
    • Windows in Uprights
    • Tie Rod Construction
    • Fabricated Steel Frame
    • Air Clutch & Brake
    • Air Counter Balances
    • Hydraulic Overload Protection
    • Light Curtains
    • Imco Tonnage Motor
    • Motor & Controls

1,000 Ton Capacity Komatsu Straight Side Press For Sale

Posted on by

1,000 Ton Capacity Komatsu Straight Side Press

  • Model: E5T1000-MF-C
  • Year: 1997
  • Capacity: 1,000 Tons
  • Bed & Slide Area: 4000mm x 1920mm (157.48″ x 76″)
  • Bolster: 4000mm x 2000mm x 270mm (157.48″ x 79″ x 11″)
  • Stroke: 450mm (18″)
  • Die Height: 1150mm (45″)
  • Adjustment: 200mm (8″)
  • Speed: 10-25 SPM
  • Includes:
    • Coil Feed Line

2,000 Ton Capacity Danly Straight Side Press

Posted on by

2,000 Ton Capacity Danly Straight Side Press

  • Model: SE-2000-180-84TF
  • Year: 1983
  • Total Capacity: 2000 Tons
  • Bed Area: 180″ x 84″
  • Slide Area: 180″ x 84″
  • Stroke: 28″
  • Slide Adjustment: 8″
  • Shut Height: 64″
  • Speed: 10 to 20 SPM
  • Windows: 136″ Wide
  • Completely Rebuilt in 2010
  • Equipped With:
    • Moving Bolsters

2000 Ton Danly Straight Side Press

Posted on by

2,000 Ton Danly Straight Side Press

Model: SE-2000-180-84TF
Year: 1983
Total Capacity: 2000 Tons
Bed Area: 180″ x 84″
Slide Area: 180″ x 84″
Stroke: 28″
Slide Adjustment: 8″
Shut Height: 64″
Speed: 10 to 20 SPM
Windows: 136″ Wide
Notes: Equipped with Moving Bolsters, Completely Rebuilt in 2010
2000 Ton Danly Press For Sale 2000 Ton Danly Press For Sale
